Introduction
This Type Of Vortex Flow Meter is developed by the principle of fluid vibration. The flow meter has no moving parts, high reliability, high precision, long life, and can be widely used. Accurate measurement of instantaneous and cumulative flow of liquid over the flow range.
Model: LUGB
MOQ: 1PCS
Payment: Bank transfer/ Wire transfer
Lead Time: 5-7 days
OEM/ODM: Available
Vortex flowmeter has small pressure loss, large measurement range, and high accuracy. It is almost unaffected by parameters such as fluid density, pressure, temperature, and viscosity. No moving mechanical parts, high reliability, low maintenance costs, and stable instrument parameters.
| Parameter | Description |
| Nominal diameter | 15~2500mm |
| Measuring medium | Liquid, gas, steam |
| Medium temperature | -40~350°C, capacitance can reach 550°C |
| Connection method | Flange, plug-in |
| Nominal pressure | 1.6MPa, 2.5MPa, 4.0 MPa and above |
| Output signal | Pulse signal, 4~20mA signal, RS485 communication output, Hart protocol |
| Accuracy class | Liquid measurement accuracy is ±1.0%, gas measurement accuracy is ±1.5% |
| Power supply | 12VDC, 24VDC, 3.6V lithium battery (more than 5 years available) |
| Repeatability | ≤0.3%, 0.5%, 1.0% |
| Body material | Stainless steel 304, stainless steel 316L |
| Load resistance | <750Ω |
| Flow rate range | Liquid 0.5~6m/s, gas 5~60m/s |
| Pressure loss | Resistance coefficient cd ≤ 2.4, small pressure loss (about 1/4 ~ 1/2 of the orifice flow meter) |
| Structure type | Flange connection type, flange clamp type, temperature and pressure integration type, insert type, sanitary type clamp type |
| Explosion-proof grade | EXiaIICT6 (intrinsic explosion-proof), EXdIIBT6 (explosion-proof) |
Industrial process control: real-time measure, monitoring and control of industrial processes in the liquid, gas and steam flow, to help users achieve process optimisation and energy saving;
Energy measurement: can be used for energy measurement, such as oil, natural gas, liquefied petroleum gas, etc. Measurement control and monitoring, for energy consumption statistics and energy saving improvement is of great significance;
Environmental protection field: can be used for sewage treatment, exhaust emissions and other environmental protection equipment flow measurement and monitoring, to ensure that environmental protection standards are met and emissions compliance;
Automobile manufacturing: can be applied to the measurement and control of coolant, fuel and other flow in the process of automobile manufacturing to ensure the safety and quality of automobile production;
Pharmaceutical and chemical industry: can be used for flow control of liquid and gas in pharmaceutical and chemical industry, including drug production, chemical reaction, drug delivery and other processes.
