Introduction
80GHz high frequency non contact type radar level transmitter has the advantages of high accuracy, narrow beam, large range and good stability. A wide range of models are available, such as high temperature resistant type, corrosion resistant type, 120meters long range type and more.
Model: GRD-80G
MOQ: 1PCS
Payment: Bank transfer/ Wire transfer
Lead Time: 5-7 days
OEM/ODM: Available
◆ Highly accurate measurement: It can provide very accurate level measurement results, and the error is usually small, which ensures the accurate measurement and control of materials in the production process.
◆ Suitable for a variety of media: whether it is liquid, solid or slurry and other different forms of media, can be effectively measured.
◆ Small blind zone: due to the high frequency characteristics, the measurement blind zone is small, can be closer to the top and bottom of the measurement vessel, improve the effective range of measurement.
◆ Rapid response: can quickly reflect the changes in liquid level, real-time, suitable for processes that require rapid adjustment of liquid level.
◆ Non-contact measurement: not in direct contact with the measured medium, will not be affected by corrosion, wear and tear of the medium, reducing maintenance costs and the possibility of equipment failure.
◆ High reliability: has a long service life and stable performance, can be in the harsh industrial conditions of long-term reliable operation.
| Parameter | Description |
| Frequency | 76GHz~81GHz |
| Range | 0.1~120m |
| Accuracy | ±2mm |
| Beam angle | 3°、8° |
| Using dielectric constant | >=2 |
| Voltage | 18~28.0VDC |
| Protocol | HART/MODBUS |
| output | 4~20mA/ HART or RS-485 |
| Fault output | 3.8mA、4mA，20mA，22mA，keep |
| Display | 128×64 Dot matrix display screen/4 buttons |
| Temperature/humidity | -40~85℃/≤95%RH |
| Housing material | Aluminum alloy/ stainless steel |
| Antenna type | Lens antenna, can be equipped with lens antenna cover/anti-corrosion antenna/antenna heat dissipation paste/quartz isolation flange plate |
| Process pressure | -0.1~2MPa |
| Electrical interface | M20*1.5/ 1/2'' NPT |
| cable | AWG18 or 0.75mm² |
| Protection level | IP65 |
| Installation | Thread/ flange |
Almost all media can be measured, even under high pressure and high temperature environment, the measurement is still stable and reliable; a variety of antenna structure, can measure corrosive liquids, can also be used in food and pharmaceutical manufacturing; solid lumps, dust, stirring, adhesion, condensation and other working conditions have the perfect solution.
Host Dimension：(unit: mm)
Probe Dimension：(unit: mm)
