Introduction
A paddle wheel flow meter is an instrument that calculates flow rate based on the amount of rotation, based on the principle that the flow rate is measured by a rotor in the middle of a pipe through which the measuring medium is flowing, and then the flow rate is calculated.
Model: GLP-KF
MOQ: 1PCS
Payment: Bank transfer/ Wire transfer
Lead Time: 5-7 days
OEM/ODM: Available
◆ High accuracy: the accuracy of the paddle wheel flow meter is usually within 1%, which can meet the needs of many occasions requiring high-precision measurement.
◆ Good stability: due to its simple measurement principle, compact structure, so the stability of the paddle wheel flow meter is very good, almost not affected by temperature, pressure and other external factors.
◆ Wide range of application: paddle wheel flow meter is not only suitable for liquid media flow measurement, can also be applied to gas media flow measurement.
◆ Convenient installation and maintenance: due to its simple structure, small size, light weight, so the installation and maintenance of the paddle wheel flow meter is very convenient.
| Parameter | Description |
| Velocity range | 0.15-8m/s |
| Diameter range | DN25-600 |
| Signal output | Square wave, 45Hz/m/s |
| Temp & Pressure | 12.5bar@25℃ |
| Wetted part | PP/PVDF/PTFE |
| Protection level | IP65/ IP68 |
| Voltage | DC5-24V |
◆ Chemical industry: paddle wheel flow meter can be used to measure the flow of various chemical media, such as acid and alkali liquids, organic solvents and so on.
◆ Petroleum industry: paddle wheel flow meter can be used for oil pipeline flow measurement, such as oil, natural gas and so on.
◆ Food industry: paddle wheel flow meter can be used as a food industry production flow meter, such as beverages, dairy products, edible oil and so on.
In short, the paddle wheel flow meter is a high precision, good stability, wide range of flow measurement instruments, in many industries have been widely used.
size for DN20-DN100 size for DN125-DN600
